USB-C outputs
Dante
Easy installation
Individually transformer isolated outputs
Mic/Line Outputs
PoE
Easy to use
TAA Compliant
Broadcast Quality
* For iPhone and iPad with lightning connector Apple Lightning to USB 3 Camera Adapter is needed together with a USB-A to USB-C cable.
| Audio Press Box APB-112 OW-D-USB | ||
|---|---|---|
| Type | 1 In 12 Out | |
| Groups | 1 | |
| Input section | ||
| Inputs | 1 | |
| Input connectors | RJ45 - Dante | |
| PoE Requirement | YES | |
| Reference level | -18dBFS | |
| Analog outputs | ||
| Outputs | 8 Line/MIC level | |
| Output connectors | Balanced, XLR | |
| Nominal Output Level | +6dBu | |
| Maximum Output Level | +20dBu (no load)
+14dBu (600Ohm) |
|
| Output impedance | Mic: 220 Ohm | Line: 600 Ohm |
| Transformer isolated outputs | Yes (each output) | |
| SNR | >70 dB | |
| Frequency Response | 80Hz to 20kHz/-3dB | |
| Digital Outputs | ||
| Output connector | USB Type C | |
| Compliant USB Specification | USB 2.0 | |
| Supported Sampling Rates | 8kHz, 11.025kHz, 16kHz, 22.05kHz, 32kHz, 44.1kHz, 48kHz | |
| Bit Depth | 16-Bit | |
| Interface Powering | Bus powered (from connected USB host device) | |
| Charging capability | No | |
| Indicators | ||
| Output section: | Output level. Power | |
| Power | ||
| Power Supply | PoE (Type 1, Class 3 (12,95W)) | |
| Mechanical | ||
| Dimensions (WxHxD) | 280x138x54mm | |
| Weight | 2400 g | |
