| Type |
1 IN/ 2 Drive OUT for 6xAPB 8-Output expanders or 2xAPB 24-Output expander
Note: Total capacity: 48 Line/Mic outputs (6x APB-008 xx-EX or 2x APB-024 R-EX) or 576 Mic Outputs (48x APB-P112 SB)
|
| Input section |
| Inputs |
1 |
| Input connectors |
Balanced, XLR |
| Max. input level |
Line: +32/+2dBu |
|
| Input Impedance |
>5kOhm |
|
| Output section |
| Outputs |
2 separately buffered, balanced outputs for AudioPressBox expanders |
| Output connectors |
Balanced, XLR |
| Nominal Output Level |
+6 dBu |
| Maximum Output Level |
+20dBu with 48 Outputs in use
+16dBu (600kOhm) |
| Output impedance |
Mic: 220 Ohm |
Line: 600 Ohm |
| Transformer isolated outputs: |
Yes (each EXPANDER output is Independant Transformer Isolated)
|
| SNR |
86dB at 0dB Gain
78dB at +20dB Gain |
| Frequency Response |
30/160Hz (filter) to 60kHz/-1dB |
| Controls |
Input gain, Compressor and Limiter, High Pass Filter, Power |
| Indicators |
Input clip, Output level, Gain reduction, Power |
| Power Supply |
24V DC, 1A external adaptor |
| Dimensions (WxHxD) |
215x120x50mm |
| Weight |
1030g |
